Reference:11NMD3480EOM

  • T47 bottom bracket allows for full internal cable routing (including Columbus Trittico cockpit) as well as improved stiffness
  • Ultralight CNC aluminium seatpost collar reduces weight and improves product life
  • seatpost tube and diameter reduces weight and improves comfort
  • As of March 2023 all Nemo frames are manufactured within the Cinelli Milan HQ by our internal framebuilder allowing us to create the world’s shortest supply chain for premium road bikes.
  • Lasercut minimalist brake bridge for further weight savings
  • Geometry
  • Custom drawn Columbus Spirit triplebutted tubes
  • Increased tyre clearance 32mm
  • Classic Italian racing geometry
  • Design-driven detailing and finish
  • Compatible Only With Electronic Groupsets
  • Available in 6 different paint + 1 Colour of the Year
€2.600,00
/

Choose your color: Oat Milk

Color Frame
Size
Order now for delivery within 30 days of purchase. All items subject to shipping and duty charges upon delivery, country-dependent.

The image has the sole purpose of presenting the product. Some assembly specifications may vary.

Book an appointment
MaterialColumbus Spirit HSS Tubeset
HeadsetIS 42/28,6 | IS 52/40
Seat ClampCNC Machined ø 29,8
BB ShellT47 68 mm
RoutingFull Internal (Super Record,Red, Dura-Ace) - External / Internal Hydraulic Disc Brake Housing
Tire Clearanceup to 700x32 mm
ForkColumbus Trittico Carbon Road
WeightFrame 2000 g. (size M) Fork 392 g. (uncut)
BrakeFlat Mount Disc Brake, rotor size up to 160 mm
Dropouts STRear TA Ø 12x142mm - M12x173 / Front TA Ø 12x100mm - M12x119
What's IncludedFrame/ Trefoil Fork / Headset / Seatpost clamp / Ft. Derailleur Clamp / Thru Axles / Fork Expander
  • Free shipping on eligible orders over €150 / $150 (EU & US - includes apparel, accessories, racewear, and bar tapes).
  • Orders shipped outside the EU: customs duties, import taxes, and tariffs are the customer's responsibility and are payable on delivery.
  • Shipments refused due to unpaid duties: return shipping, carrier clearance fees, and any duties incurred will be deducted from the refund. If these costs equal or exceed the order value, no refund is issued.

Full shipping policy ->

NEMO TIG ROAD - FRAME-KIT geometry
What is my size?

If you are unsure about your size, please refer to the frame specs on the product page or contact us here. Include your height and inseam measurements, or a biomechanical data sheet. Our customer service team will help you choose the right size.

Can I buy just the frameset?

You can buy the frameset alone for the following models: Tutto Mini, Hobootleg Geo, Hobootleg Easy Travel, Aeroscoop, King Zydeco II, Pressure II, Speciale Gravel, Pressure ADR, Speciale Corsa XCR, Nemo Road, Supercorsa, Supercorsa Pista, Vigorelli.

What bikes are made in Italy?

All Speciale Gravel, Nemo Road, Speciale Corsa XCR, and Supercorsa models are made in Italy. See the bikes here: Made In Italy Bikes – Cinelli Official

Can I change the assembly components?

You can change stem length and handlebar width. For mechanical parts such as cassettes, cranksets, chainrings, or wheels, you may upgrade with third-party components after purchase. Before buying upgrades, we recommend referencing our Cinelli component mapping tool or contacting us for a compatibility check, and having an official dealer handle the assembly.

How can I activate my warranty?

The warranty is automatically activated after payment. Fill out the warranty card included in your bike box and keep your receipt. You can also submit the warranty card and receipt via the Contact Us form, and we will archive them for you.

About this product

The Nemo is Cinelli’s flagship steel road bike, handcraft to hybridize our more than 75 years of Italian cycling heritage with the performance possibilities of contemporary cold-drawn steel tubing technology. Every Nemo frame is handwelded by Cinelli’s internal framebuilder in its Milanese HQ, using custom drawn triple butted tube drawn by its sister company Columbus, less than 100 metres from the framebuilder creating the world’s shortest performance bicycle supply chain. For 2024 – thanks to continuous three-way dialogue between the Cinelli design office, our framebuilder and Columbus – the Nemo has undergone subtle but significant manufacturing improvements including a 170g weight reduction (size Medium), the introduction of the T47 bottom bracket allowing for fully-internal cable routing as well as improving stiffness and a new ultralight CNC’d aluminium seatpost collar.

Reference: 11NMD3480EOM
